Casement windows
Thermally broken window that allows for both side hung and top hung outward openings. This solution, with a thermal break zone of 32 mm and a transmittance Uw from 1.0 W/m²K, has the British security certification PAS 24, being especially suitable for this market.
Section Type
Features
Sightlines Frame
70 mm, Sash 70 mm
Polyamide strip length
32 mm
Profile thickness Window
1.6 mm
Glazing Max.
44 mm, Min. 23 mm
Maximum sash dimensions
Slim sash (Side hung): Width (L) 950 mm, Height (H) 1,300 mm
Slim sash (Top hung): Width (L) 1,200 mm, Height (H) 1,300 mm
Heavy Duty sash (Side hung): Width (L) 750 mm, Height (H) 1,750 mm
Heavy Duty sash (Top hung): Width (L) 1,800 mm, Height (H) 1,800 mm
Maximum sash weight
Side Hung Slim Sash: 35 kg
Top Hung Slim Sash: 50 kg
Side Hung Heavy Duty Sash: 42 kg
Top Hung Heavy Duty Sash: 100 kg
Consult maximum weight and dimensions according to typologies
Hardware
