Cor Vision

Thermally broken minimalist sliding system that provides maximum luminosity with a minimal aluminium interlock profile. It has an elegant design only 20 mm sightline and offers the possibility of an inlaid closing system and of hiding the frame along the perimeter.

Section Type

Double Track

double track.png

HIDDEN TRACK SOLUTION

hidden track.png

INTERLOCK HANDLE

INTERLOCK HANDLE.png

BESPOKE DRAINAGE SOLUTION

bespoke drainage solution.png

Features

Sightlines

Frame depth 116 mm / 182 mm 3 rails

Sash depth 37 mm

Interlock

20 mm

Polyamide Strip Length

16 / 24 mm

Profile Thickness

Door 1.7 mm

Glazing Max.

30 mm, Min. 26 mm

Maximum Sash Dimensions

Width (L) 2500 mm, Height (H) 3000 mm

Maximum Sash Weight

320 kg

*Consult maximum weight and dimensions according to typologies*

vision U Value .png

Hardware
